SPECIAL BEARINGS

Special Bearings are bearings that are provided for special projects

Special Bearings are bearings that are provided for special projects. Special Bearings are intended for purposes that require bearings of different sizes to bearings in general, usually applied to large sized machines, for example tunnel boring machines, bucket-wheel excavators and dump trucks in the mining industry.

The bearings that we provide in this special bearing are from well-known brands of course with very good quality, namely the RKB Bearing brand .

RKB

RKB

In short, RKB is a Swiss company with more than 80 years of experience in bearing manufacture and design, especially in medium and large size bearings , as well as bearing technology . RKB has one of the largest holdings in Europe worth more than 80 million euros. By having customers from various industries such as the cement, mining and marble industries. We provide large size bearings and bearing technology that can be used in special projects. RKB has bearing products that can support areas such as:

  • Civil Engineering Applications
  • Marine and Offshore
  • Metals
  • Mines and Minerals
  • Power Transmission
  • Heavy Automotive
  • etc



CIVIL ENGINEERING APPLICATIONS



DISC CUTTER FOR TUNNEL BORING MACHINE

Disc cutter for tunnel boring machine1
MAIN RKB BEARINGS:
T3 SEGMENT - SINGLE ROW TAPERED ROLLER BEARINGS

  • Thin section large size single row tapered roller bearings (design and execution for heavy load applications)
  • Up to 458 mm inner diameter
  • B 10 life > 100000 h as per mining specifications



PULP AND PAPER, CONVERTING AND PRINTING

PULP AND PAPER, CONVERTING AND PRINTING1
MAIN RKB BEARINGS: T3 SEGMENT - SPHERICAL ROLLER BEARINGS

  • Premium class bearings for extended service life
  • Spherical, tapered and cylindrical roller bearings



MARINE AND OFFSHORE

MAIN SHAFT OF NAVY FRIGATE

Main shaft of navy frigate1
MAIN RKB BEARINGS:
T3 SEGMENT - SPHERICAL ROLLER BEARINGS

  • Large size application-optimized spherical roller bearings
  • Up to 340 mm inner diameter
  • Safety factor (S 0 ) according to military offshore equipment guidelines



JACKING SYSTEM IN OFFSHORE PLATFORM

JACKING SYSTEM IN OFFSHORE PLATFORM1


MAIN RKB BEARINGS:
T3 SEGMENT - SPHERICAL ROLLER BEARINGS

  • Spherical roller bearings for rack and pinion jacking system of NG and CJ series drilling rigs working in harsh
    environmental conditions
  • Up to 240 mm inner diameter
  • Design and execution to withstand heavy loads and variable speeds (0.3-1.2 m/ min)
  • Safety factor (S 0 ) as per marine specifications
  • Design life (L 10 ) ≈ 10 years service



METALS



GUIDE ROLLS OF CONTINUOUS SLAB CASTING MACHINE

Guide Roll of Continuous slab casting machine1


MAIN RKB BEARINGS:
T3 SEGMENT - SINGLE ROW TAPERED ROLLER BEARINGS

  • Low cross section spherical roller bearings for guide rolls of continuous slab casting in hot strip mills
  • Up to 170 mm outer diameter
  • Out of standard window-type cage
  • Stabilizing Treatment for operating temperatures up to 300 °C (S3)



WORK ROLLS OF HOT ROLLING MILL STAND

Work rolls of hot rolling mill stand1


MAIN RKB BEARINGS:
T3 SEGMENT - SEALED FOUR-ROW TAPERED ROLLER BEARINGS

  • Long life series bearings
  • Phosphate Treatment for rings, rollers and spacers (PT4)
  • Increase of rolling efficiency by stable operation
  • Easier handling of seals



MINES AND MINERALS



BUCKET WHEEL EXCAVATOR MAIN SHAFT

Bucket Wheel Excavator Main Shaft1


MAIN BEARINGS:
T3 SEGMENT - SPLIT DOUBLE ROW CYLINDRICAL ROLLER BEARINGS

  • Time saving in hard-to-reach positions
  • Manufacturing technology and expertise for maximum reliability
  • Engineered for modified ISO life (L 10mh ) > 20000 h
  • Up to 780 mm outer diameter
  • Safety factor (S 0 ) > 3



CONE TYPE CRUSHER

Cone Type Crusher1


MAIN RKB BEARINGS:
T3 SEGMENT - TECHNOLOGICAL BEARINGS

  • Technological double row cylindrical roller and thrust roller bearings
  • Superior load capacities
  • Optimized design of inner executions for improved lubrication and resistance to high vibrations/shocks



POWER TRANSMISSION



WIND MULTIPLICATOR

Wind Multiplicator1


MAIN RKB BEARINGS:
T3 SEGMENT - TECHNOLOGICAL BEARINGS

  • Technological bearings for speed multiplicators used in medium and high power wind turbines (over 850 kW)
  • Maximum reliability required due to the application conditions
  • Bearing optimization through RKB R&D activity



CONCRETE MIXER GEARBOX

Concrete Mixer Gearbox1


MAIN RKB BEARINGS:
T3 SEGMENT - SPHERICAL ROLLER BEARINGS WOR DESIGN

  • Bearing internal geometry optimized through Finite Element Analysis to sustain additional loads and friction
    at low operating speeds (max 20 rpm)
  • Increased permissible misalignment up to ±6° (Wider Outer Ring) in transit mixer concrete gearbox
  • Premium steel class for higher reliability and extended service life
  • Special heat treatments to reduce incidence of cracking
  • Safety factor (S 0 ) > 2.5
  • Design life (L 10m ) > 2.6 million revolutions ≈ 10 years service



HEAVY AUTOMOTIVES



FRONT AND REAR AXLES OF DUMP TRUCK

Front and rear axles of dump truck1


MAIN RKB BEARINGS:
T3 SEGMENT - SINGLE ROW TAPERED ROLLER BEARINGS

  • Single row tapered roller bearings for dumper transmission (wheel hubs of front and rear axles)
  • Up to 300 mm inner diameter and 422 mm outer diameter
  • E-Type design and execution for high load capacity, higher accuracy and shock resistance
  • Life rating (L 10 ) > 100000 km of the vehicle



GEARBOX FOR CITY BUS ON TIRES

Gearbox for city bus tyres1


MAIN RKB BEARINGS:
T3 SEGMENT - TECHNOLOGICAL BEARINGS

  • Application optimized tapered and cylindrical roller bearings
  • Up to 280 mm inner diameter
  • Required operating life (L 10m ) > 1.8 million kilometers of the vehicle
